Avoid using or servicing any equipment that has outdoor connections during an electrical storm. There may
be a risk of electric shock from lightning. Statement 1088
Warning
Hazardous network voltages may be present in interface ports regardless of whether power to the unit is OFF
or ON. To avoid electric shock, before servicing, disconnect cables from the following ports: T1/E1 Statement
1026
Warning
LTE NIMSsupported are:
• NIM-LTEA-EA
• NIM-LTEA-LA
To reduce the risk of electric shock, the shield of the coaxial cable must be connected to the building earth.
Statement 1253
Warning
To reduce the risk of electric shock, refer to national and local codes for proper installation and grounding of
antennas. Statement 1052
Warning
Installing and Removing a NIM
These are the steps to install a NIM:
• Locate the NIM slot on the front panel.
• Loosen the screws to open the NIM blank cover.
• Insert the NIM into the slot.
• Tighten the screws to secure the NIM in the slot.
These are the steps to remove a NIM:
• If the NIM is up and running, shut down the NIM gracefully before removing it:
If you do not shut down the NIM gracefully before removing it, the NIM card could get damaged.
Warning
• Locate the NIM slot on the front panel.
• Loosen the screws that secure the NIM.
• Gently pull out the NIM from the slot
Hardware Installation Guide for the Cisco 1100 Terminal Gateway
38
Install and Remove Small Form Pluggable Modules and Field Replaceable Units
Installing and Removing a NIM
