Cisco 1100 Series Hardware Installation Guide

CHAPTER 1
About Cisco 1100 Terminal Gateway Routers
Cisco 1100 Terminal Gateway Routers are terminal servers that provides asynchronous connections to the
console ports for Cisco devices.
Table 1: Base Models of the Cisco 1100 Terminal Gateway Routers
MemorySwitchNIM SlotAsynchronous PortsBase Models
2GB Dram/ 4GB
flash
NoneYes32C1100TG-1N32A
4GB Dram/ 4GB
flash
24 port L2 SwitchYes32C1100TG-1N24P32A
8GB Dram/ 8GB
flash
24 port L2 SwitchYes32C1100TGX-1N24P32A
For more information on the features and specifications of Cisco 1100 Series Terminal Gateway Routers,
refer to Cisco 1100 Terminal Gateway Routers datasheet.
• Chassis Views, on page 1
• LED Indicators, on page 3
• Power Supply, on page 5
• Slots and Interfaces, on page 5
• Fans, Ventilation and Airflow, on page 8
• Specifications of Cisco 1100 Series Integrated Services Routers, on page 10
• Periodic Inspection and Cleaning, on page 10
Chassis Views
This section contains front and back panel views of the Cisco 1100 Terminal Gateway Routers-showing
locations of the power and signal interfaces, interface slots, status indicators, and chassis identification labels.
Hardware Installation Guide for the Cisco 1100 Terminal Gateway
1

Cisco 1100 Series Specifications

General

Form Factor	Desktop
Model	Cisco 1100 Series
Integrated Wi-Fi	Yes, 802.11ac Wave 2
Security	Firewall, VPN (IPsec, DMVPN, FlexVPN), intrusion prevention, content filtering
Management	Cisco IOS XE
Power Supply	External power adapter
Power	12V DC
Mounting	Desktop
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20 to 70°C (-4 to 158°F)
