Cisco 1100 Series Hardware Installation Guide

root@usb-suse# cd /dev
root@usb-suse /dev# ls -ltr *ACM*
crw-r--r-- 1 root root 188, 0 Jan 14 18:02 ttyACM0
root@usb-suse /dev#
Step 4 Connect to the USB port with the following command followed by the router USB port speed
Example:
root@usb-suse /dev# screen /dev/ttyACM0 9600
To disconnect the Linux USB console from the Terminal window
Enter Ctrl-a followed by : then quit
Connect WAN and LAN Interfaces
This section describes how to connect WAN and LAN interface cables. Before you connect the interface
cables, refer to the following warning statements:
For connections outside the building where the equipment is installed, the following ports must be connected
through an approved network termination unit with integral circuit protection: LAN, Ethernet. Statement
1044.
Warning
Ports and Cabling
This section summarizes typical WAN and LAN connections for Cisco 1100 Terminal Gateway Server.
Table 3: WAN and LAN Connections
CableConnectionPort Type, ColorPort or Connection
Category 5 or higher
Ethernet
Ethernet hub or Ethernet
switch
RJ-45, yellowEthernet
Optical fiber as specified on
applicable data sheet
GLC-SX, -LX, -LH, -ZX,
-BX, -EX, -TE
LC, color according to
optical wavelength
Gigabit Ethernet SFP,
optical
Category 5, 5e, 6 UTP1000BASE-TRJ-45Gigabit Ethernet SFP,
copper
Supported cables for Async Ports
For asynchronous serial ports new Cable CAB-ASYNC-8 is supported.
Hardware Installation Guide for the Cisco 1100 Terminal Gateway
33
Install and Connect the Router
Connect WAN and LAN Interfaces

Cisco 1100 Series Specifications

General

Form Factor	Desktop
Model	Cisco 1100 Series
Integrated Wi-Fi	Yes, 802.11ac Wave 2
Security	Firewall, VPN (IPsec, DMVPN, FlexVPN), intrusion prevention, content filtering
Management	Cisco IOS XE
Power Supply	External power adapter
Power	12V DC
Mounting	Desktop
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-20 to 70°C (-4 to 158°F)
