ATM Line Card Installation and Configuration
OL-13004-01
Important Information
Table 2 lists the Cisco IOS releases and other software components that are compatible with the various
ATM line cards.
The show version and show hardware commands display the current hardware configuration of the
router, including the system software version that is currently loaded and running. For complete
descriptions of show commands, refer to the Cisco IOS Configuration Fundamentals Configuration
Guide and the Cisco IOS Configuration Fundamentals Command Reference for the installed Cisco IOS
Release and see the “Using show Commands to Check Status” section on page 34.
Hardware Revision Requirements
To ensure compatibility with the software, your ATM line card should have a specific hardware revision
number. This number is printed on a label affixed to the component side of the card. The hardware
revision number can also be displayed using the show version command.
Table 3 lists the hardware revision numbers for all ATM line cards.
Table 2 ATM Line Card and Software Component Compatibility
ATM Line Card Compatible Cisco IOS Release
1-port OC-12c/STM-4c 11.2(9) or later
4-port OC-3c/STM-1 11.2(4)GS1 or later
4-port OC-12c/STM-4c 12.0(13)S or later 12.0 S release
8-port OC-3c/STM-1 12.0(22)S or a later 12.0 S release
4-port OC-3c/STM-1 ISE 12.0(26)S2, 12.0(27)S1 or a later 12.0 S release
4-port OC-12c/STM-4c ISE 12.0(25)S or a later 12.0 S release
Table 3 ATM Line Card Hardware Revision Numbers
ATM Line Card Hardware Revision Number
1
1. Hardware revision numbers that are higher than those listed are also compatible. These are the minimum
required numbers.
1-port OC-12c/STM-4c 73-2526-04 rev. A0 for multimode
73-2525-04 rev A0 for single-mode
4-port OC-3c/STM-1 78-3034-02 rev. A0 for multimode
73-3033-02 rev. A0 for single-mode
4-port OC-12c/STM-4c 800-05669-02 rev. A0, 73-3983-05 rev. A0 for multimode
800-05606-02 rev. A0, 73-3984-05 rev. A0 for single-mode
8-port OC-3c/STM-1 73-7919-02 for multimode
73-7920-02 for single-mode
4-port OC-3c/STM-1 ISE 800-24352-01 for multimode
800-24341-01 for single-mode
4-port OC-12c/STM-4c ISE 800-20757-01 for multimode
800-20368-01 for single-mode
