ATM Line Card Installation and Configuration
OL-13004-01
Important Information
• Hardware Revision Requirements, page 3
• Related Documentation, page 4
ATM Line Card Product Numbers
Table 1 lists the Cisco product numbers to which this publication applies.
Router Hardware Installation
For hardware installation and configuration information for Cisco 12000 series routers, refer to the
installation and configuration guide for your router. The guide includes information on the router switch
fabric and its affect on operation of the line card, as well as line card slot locations and other
requirements.
Supported Platforms
The ATM line card is supported on all Cisco 12000 series routers.
Note The installation procedure of the 4-port ISE ATM line card in the Cisco 12008 and Cisco 12012 Routers
is slightly different than that for other routers in the series. Take note of the differences in the installation
sections.
Cisco IOS Software Release Requirements
For software configuration information, refer to the Cisco IOS software configuration and command
reference publications for the installed Cisco IOS software release. Also, refer to the Cisco IOS software
release notes for additional information.
Table 1 ATM Line Card Product Numbers
ATM Line Card Cisco Product Number
1-port OC-12c/STM-4c multimode LC-1OC12/ATM-MM=
1-port OC-12c/STM-4c single-mode LC-1OC12/ATM-SM=
4-port OC-3c/STM-1 multimode 4OC3/ATM-MM-SC=
4-port OC-3c/STM-1 intermediate-reach 4OC3/ATM-IR-SC=
4-port OC-12c/STM-4c multimode 4OC12/ATM-MM-SC=
4-port OC-12c/STM-4c intermediate-reach 4OC12/ATM-IR-SC=
8-port OC-3c/STM-1 multimode 8OC03/ATM/TS-MM=
8-port OC-3c/STM-1 intermediate-reach 8OC03/ATM/TS-IR=
4-port OC-3c/STM-1 ISE multimode 4OC3X/ATM-MM-SC=
4-port OC-3c/STM-1 ISE intermediate-reach 4OC3X/ATM-IR-SC=
4-port OC-12c/STM-4c ISE multimode 4OC12X/ATM-MM-SC=
4-port OC-12c/STM-4c ISE intermediate-reach 4OC12X/ATM-IR-SC=
