Preparing for Installation
Figure 5 shows the front view of the 4-port ISE ATM line card.
Figure 5 4-port ISE ATM Line Card
Preparing for Installation
Before you begin the installation process, review the important information in the following sections:
• Safety Guidelines, page 7
• Preventing Electrostatic Discharge, page 8
• Required Tools and Equipment, page 8
Safety Guidelines
Before you perform any procedure in this publication, review the safety guidelines in this section to
avoid injuring yourself or damaging the equipment.
The following guidelines are for your safety and to protect equipment. The guidelines do not include all
hazards. Be alert.
Note Review the safety warnings listed in the Regulatory Compliance and Safety Information for
Cisco 12000 Series Internet Router publication (Document Number 78-4347-xx) that accompanied your
router before installing, configuring, or maintaining a line card.
• Keep the work area clear and dust free during and after installation. Do not allow dirt or debris to
enter into any laser-based components.
• Do not wear loose clothing, jewelry, or other items that could get caught in the router while working
with line cards.
• Cisco equipment operates safely when it is used in accordance with its specifications and product
usage instructions.
1 Ejector lever 3 Status LEDs
2 Port 0 4 Display LEDs
4OC12X/ATM-MM-SC
O
1
Tx
Rx
0
Tx
Rx
2
Tx
Rx
3
Tx
Rx
LED DENOTATION
CARRIER
RX CELL
ACTIVE
CLEAN
CONNECTOR
WITH ALCOHOL
WIPES BEFORE
CONNECTING
84923
1
4
2
3
Cisco Systems, Inc.
170 W Tasman Drive
San Jose, Ca 95134
Manufactured
xxxxxxxx xxxx:
Complies with 21 CFR
Chapter 1, Subchapter J
CNS68V4AAA
