1-4
Cisco Connected Grid Routers 2010 Hardware Installation Guide
OL-21559-01
Chapter 1 Overview of the Router
Hardware Features
Built-in Interface Ports
Table 1-1 summarizes the interface ports built into the router chassis.
Gigabit Ethernet Ports
There are two different types of GE ports available on Cisco 2010 CGR.
• GE Ports, page 1-4
• SFP Ports, page 1-4
GE Ports
The GE RJ-45 copper interface ports support 100BASE-TX and 1000BASE-T.
SFP Ports
The small form factor pluggable (SFP) ports on the Cisco 2010 CGR support the following rugged SFP
SKUs:
• GLC-FE-100FX-RGD=
• GLC-FE-100LX-RGD=
• GLC-SX-MM-RGD=
• GLC-LX-SM-RGD=
• GLC-ZX-SM-RGD=
The SFP port shares the same physical port as an RJ-45 GE port.
The SFP port can be configured for the following behaviors:
• Always use the RJ-45 port.
• Always use the SFP port.
USB Console Port
The Mini-USB type B port has been enabled to perform management tasks on the router. To use this port,
you must install a Windows USB device driver before establishing physical connectivity between a
personal computer and the router. See the
“Installing the Cisco Microsoft Windows USB Device Driver”
section on page 3-13 for driver installation instructions.
4. GRWIC slots 0, 1, 2, and 3 (0, far right).
5. For T1/E1 interfaces, shielded cables are required to meet EN55022, Cispr 22, and EN300-386 compliance.
Ta b l e 1-1 Summary of Cisco 2010 CGR Built-In Interfaces
Data Ports Management Ports
Router
Model
10/100/1000
GE RJ-45
100/1000
SFP
USB Type A
Console,
Serial, RJ-45
Console,
Mini-USB (Type B)
Auxiliary,
RJ-45
Cisco 2010
CGR
2 2 2 1 1 1
