Chapter 1 Cisco 3200 Rugged Enclosures
Cisco 3230 Rugged Enclosure
The Cisco 3230 Rugged Enclosure is designed to accommodate the Mobile Access Router Card
(MARC). This enclosure operates in a temperature range from –40 to 165°F (–40 to +74°C), and is
certified to meet NEMA4 requirements.
Figure 1-4 shows an example of a Cisco 3230 Rugged
Enclosure.
Figure 1-4 Cisco 3230 Rugged Enclosure
1 Front of the enclosure (I/O end cap)
1
1. This end cap shows four serial ports, but the typical configuration has two serial ports.
2 Back of the enclosure (antenna end cap)
270442
2
1
