Chapter 6 Wireless Mobile Interface Cards
LED Behavior
During normal operations, the indicator signals (LEDs) on the wireless device have the following
meanings:
• The status indicator signals operational status. Steady green indicates that the wireless device is
associated with at least one wireless client. Blinking green indicates that the wireless device is
operating normally but is not associated with any wireless devices.
• The radio indicator blinks green to indicate radio traffic activity. The light is normally off, but it
blinks whenever a packet is received or transmitted over the radio.
• The Ethernet indicator signals traffic on the wired LAN. This indicator is normally green when an
Ethernet cable is connected. The indicator blinks green when a packet is received or transmitted over
the Ethernet infrastructure. The indicator is off when the Ethernet cable is not connected.
Table 6-1 lists the details of LED indicator signals.
Ta b l e 6-1 Indicator Signals
Message
Type
Ethernet
Indicator
Status
Indicator
Radio
Indicator Meaning
Boot loader
status
Green — Green DRAM memory test.
— Amber Red Board initialization test.
— Blinking
green
Blinking
green
Flash memory test.
Amber Green — Ethernet initialization test.
Green Green Green Starting Cisco IOS software.
Association
status
— Green — At least one wireless client device is
associated with the unit.
— Blinking
green
— No client devices are associated; check the
wireless device service set identifier
(SSID) and Wired Equivalent Privacy
(WEP) settings.
Operating
status
— Green Blinking
green
Transmitting/receiving radio packets.
Green — — Ethernet link is operational.
Blinking
green
— — Transmitting/receiving Ethernet packets.
Boot Loader
Errors
Red — Red DRAM memory test failure.
— Red Red File system failure.
Red Red — Ethernet failure during image recovery.
Amber Green Amber Boot environment error.
Red Green Red No Cisco IOS image file.
Amber Amber Amber Boot failure.
