Commutateurs gérés empilables série 500 63
Fonctionnalités extérieures du
commutateur géré empilable Cisco
série 500
Cette section fournit une description des éléments extérieurs du
commutateur, notamment des ports, des voyants DEL et des connecteurs.
Panneau avant
Les ports et les DEL sont situés sur le panneau avant du commutateur.
Côté gauche du commutateur de la gamme 500X
Côté gauche du commutateur de la gamme 500
Côté gauche du commutateur SG500XG-8F8T
4
SG500X-24P 24-Port Gigabit with 4-Port 10-Gigabit PoE Stackable Managed Switch
1
1
2
3
4
13 2 14
PoE
LINK
ACT
Master
Fan
370001
System
Reset
Stack ID
SG500-28P 28-Port Gigabit PoE Stackable Managed Switch
1
1
2
3
4
13 2 14
PoELINK
ACT
Master
Fan
370006
System
Reset
Stack ID
