Cisco 5510 - ASA SSL / IPsec VPN Edition Hardware Installation Guide

B-11
Cisco ASA 5500 Series Hardware Installation Guide
OL-10089-01
Appendix B Maintenance and Upgrade Procedures
Removing and Replacing the CompactFlash
Step 6 Carefully slide the CompactFlash out of its connector as shown in Figure B-11. The CompactFlash has a lip
on its lower edge, which you can use to grip the CompactFlash. Otherwise, use sliding pressure with your
thumb or finger to slide the CompactFlash out of its connector.
Figure B-11 Removing the System CompactFlash
1 System CompactFlash
119580
1
