GPP_* (under specific conditions)
Within these parameters, syntax types, such as $NAME or $(NAME), are recognized and expanded.
Macro variable substrings can be specified with the notation $(NAME:p) and $(NAME:p:q), where p and q
are non-negative integers (available in revision 2.0.11 and above). The resulting macro expansion is the
substring starting at character offset p, with length q (or else till end-of-string if q is not specified). For example,
if GPP_A contains ABCDEF, then $(A:2) expands to CDEF, and $(A:2:3) expands to CDE.
An unrecognized name is not translated, and the $NAME or $(NAME) form remains unchanged in the
parameter value after expansion.
Description and Default ValueParameter Name
The form $$ expands to a single $ character.$
Replaced by the contents of the general purpose parameters GPP_A
through GPP_P.
A through P
Replaced by special purpose parameters GPP_SA through GPP_SD.
These parameters hold keys or passwords used in provisioning.
$SA through $SD are recognized as arguments to the optional
resync URL qualifier, --key.
Note
SA through SD
MAC address using lower case hex digits, for example, 000e08aabbcc.MA
MAC address using upper case hex digits, for example
000E08AABBCC.
MAU
MAC address using lower case hex digits, and colons to separate hex
digit pairs, for example 00:0e:08:aa:bb:cc.
MAC
Product Name. For example, CP-6841-3PCC.PN
Product Series Number. For example, 6841-3PCC.PSN
Serial Number string, for example 88012BA01234.SN
SSL Client Certificate status: Installed or Not Installed.CCERT
IP address of the phone within its local subnet, for example
192.168.1.100.
IP
External IP of the phone, as seen on the Internet, for example
66.43.16.52.
EXTIP
Software version string. For example, sip78xx.11-0-1MPP.SWVER
Hardware version string, for example 2.0.1HWVER
Cisco IP Phone 6800 Series Multiplatform Phones Provisioning Guide
68
Provisioning Parameters
Macro Expansion Variables
