Figure 24: Mounting Holes
Mounting Hole on the Phone1
Wall Mount Pin on the Wall Mount Plate2
Step 8 Firmly slide the phone down into place as shown in the following image:
Figure 25: Sliding the IP Phone
Cisco IP Phone 6800 Series Multiplatform Phones User Guide
194
Accessories
Install the Cisco IP Phone 6821 Multiplatform Phones on a Wall
