Auxiliary port6AC-to-DC power supply (optional)2
Handset connection7AC power cord (optional)3
Analog headset connection (optional)8Network port (10/100 SW) for connecting
to the network
4
Footstand
If your phone is placed on a table or desk, the footstand can be connected to the back of the phone for a higher
or lower viewing angle, depending on your preference.
Footstand slots for a lower viewing angle2Footstand slots for a higher viewing angle1
Cisco Unified IP Phone 6945 User Guide for Cisco Unified Communications Manager Express Version 8.8 (SCCP)
OL-24413-01 5
Overview
Footstand

Cisco 6945 Specifications

General

Resolution	320 x 240 pixels
Speakerphone	Yes
Protocols	SIP, SCCP
Ethernet	10/100 Mbps
Power	IEEE 802.3af PoE or optional external power adapter
Audio	Full-duplex speakerphone
Headset Port	Yes, RJ9
Supported Codecs	G.711, G.722, G.729a, iLBC
