Chapter 3 Installing a Cisco 7200 VXR Router
Connecting I/O Controller, NPE-G1, or NPE-G2 Cables
The Cisco 7200 VXR routers ship with a roll-over cable. Connection to a terminal or a modem will
require an RJ-45-to-DB-25 adapter, and possibly a DB-25-to-DB9 adapter. Refer to
Table 3-17 for the
cable and adapter configurations that can be used to connect terminals and modems to the Cisco 7200
VXR routers.
RJ-45 Console Port Signals and Pinouts
The NPE-G1, NPE-G2, and the C7200-I/O-2FE/E and C7200-I/O-GE+E I/O controllers do not support
Data
Carrier Detect (DCD). Table 3-18 lists the RJ-45 console port signals for the NPE-G1, NPE-G2,
and the C7200-I/O-2FE/E and C7200-I/O-GE+E I/O controllers.
RJ-45 Auxiliary Port Signals and Pinouts for the NPE-G2, NPE-G1 and I/O Controllers
Table 3-19 lists the RJ-45 auxiliary port signals for the C7200-I/O-2FE/E and C7200-I/O-GE+E I/O
controllers and NPE-G1, and NPE-G2
Ta b l e 3-17 Asynchronous Device Cabling Options
Access Server Port RJ-45 Cable Type DB-25 Adapter End Device
Console or auxiliary Roll-over FDTE
1
1. The FDTE RJ-45-to-DB-25 adapter is labeled “Terminal”.
Terminal
Console or auxiliary Straight FDCE Terminal
Console or auxiliary Roll-over MMOD
2
2. The MMOD RJ-45-to-DB-25 adapter is labeled “Modem”.
Modem
Ta b l e 3-18 Console Port Signals for NPE-G1, NPE-G2, and C7200-I/O-2FE/E and
C7200-I/O-GE+E
Pin
1
1. Any pin not referenced is not connected.
Signal Direction Description
1 CTS Out Clear To Send (tracks RTS)
2 DSR Out Data Set Ready (always on)
3 RXD Out Receive Data
4 GND — Ground
6 TXD In Transmit Data
7 DTR In Data Terminal Ready
8 RTS In Ready To Send
Ta b l e 3-19 Auxiliary Port Signals for NPE-G2, NPE-G1 and C7200-I/O-2FE/E and C7200-I/O-GE+E
Pin
1
Signal Direction Description
1 RTS Out Ready To Send
2 DTR Out Data Terminal Ready
3 TXD Out Transmit Data
4
2
RING In Ring Indication
