Cisco 7206VXR - VPN Bundle Router User Manual

4-11
Cisco 7200 VXR Installation and Configuration Guide
OL-5013-09
Chapter 4 Observing System Startup and Performing a Basic Configuration
Configuring a Cisco 7200 VXR Router
Step 2 Determine if you are going to enable IPX on this interface; if you are, enter the unique IPX network
number:
Configure IPX on this interface? [no]: yes
IPX network number [2]:
Step 3 If you are using AppleTalk on the interface, enter yes. Enter yes to configure for extended AppleTalk
networks, and then enter the cable range number. Enter the zone name and any other additional zones
that are associated with your local zone:
Configure AppleTalk on this interface? [no]: yes
Extended AppleTalk network? [no]: yes
AppleTalk starting cable range [0]:
Note If additional ATM interfaces are available in your system, you are prompted for their configurations as
well.
Step 4 Save your settings to NVRAM. (See the “Saving the Running Configuration to NVRAM” section on
page 4-15.)
Configuring Fast Ethernet Interfaces
In the following example, a Fast Ethernet interface in slot 2 is configured for a Fast Ethernet LAN using
IP. Follow these steps to configure Fast Ethernet interfaces.
Step 1 Using your own addresses and mask at the setup prompts, respond to the prompts as follows:
Configuring interface parameters:
Configuring interface FastEthernet2/0:
Is this interface in use? [yes]:
Use the 100 Base-TX (RJ-45) connector? [yes]:
Operate in full-duplex mode? [no]:
Configure IP on this interface? [yes]:
IP address for this interface: 1.1.1.20
Number of bits in subnet field [0]:
Class C network is 1.1.1.0, 0 subnet bits; mask is /24
Step 2 Determine if you are going to enable IPX on this interface; if you are, enter the unique IPX network
number:
Configure IPX on this interface? [no]: yes
IPX network number [2]:
Step 3 If you are using AppleTalk on the interface, enter yes. Enter yes to configure for extended AppleTalk
networks, and then enter the cable range number. Enter the zone name and any other additional zones
that are associated with your local zone:
Configure AppleTalk on this interface? [no]: yes
Extended AppleTalk network? [no]: yes
AppleTalk starting cable range [0]:
