Chapter 1 Cisco 7200 VXR Product Overview
Field-Replaceable Units
NPE-G1 LEDs
USB USB ports Flashing green Activity.
Off No activity.
CF ACTV CompactFlash
Disk
Flashing green Activity.
Off No activity.
SYST STAT System status Solid green Cisco IOS has successfully booted.
Flashing yellow ROMmon is loading.
Solid yellow ROMmon has successfully booted.
Flashing green Cisco IOS is loading.
PWR OK Power Green The NPE-G2 has powered on.
Off No activity.
Ta b l e 1-26 NPE-G1 LEDs
LED Label LED Color LED Status in the Power Up State LED Flashes when
There Is Traffic
LINK, 0/1, 0/2,
0/3
RJ-45 and
GBIC ports
Green On, indicating that a link has been
established.
No
EN (Enable),
0/1, 0/2, 0/3
RJ-45 ports
only
Green On, if the RJ-45 port is selected.
Off, if the GBIC port is selected.
—
SLOT ACTIVE CompactFlash
Disk
Green On when the slot is being used. —
POWER ON Power Green On and stays on. No
Table 1-25 NPE-G2 LEDs (continued)
LED Label LED Color Status in the Power Up State
