Cisco 7200 VXR Installation and Configuration Guide
OL-5013-09
Chapter 1 Cisco 7200 VXR Product Overview
Physical Description
See Table 1-1 for the Cisco 7200 VXR physical specifications and power requirements:
Ta b l e 1-1 Physical Specifications
Description Specification
Midplane Two primary PCI buses, and one secondary PCI bus
• With an NPE-G2 or NPE-G1 and an I/O controller installed, the I/O controller does not use
bandwidth points, and the NPE-G2 or NPE-G1 does use bandwidth points. The NPE-G2 or
NPE-G1 does not use bandwidth points if installed without the I/O controller.
• With an NSE-1, NPE-400, or NPE-300 installed: aggregate bandwidth of 900 Mbps
1
• With n NPE-100, NPE-150, or NPE-200 installed: aggregate bandwidth of 600 Mbps
Three primary PCI buses—With the NPE-G2 or NPE-G1 installed, no I/O controller, and the Port
Adapter Jacket Card installed, three PCI buses are available. Aggregate bandwidth of the PCI buses
is 900 Mbps. The third PCI bus goes to the Port Adapter Jacket Card and provides unlimited
bandwidth for one port adapter.
Dimensions
(H x W x D)
5.25 in. x 16.8 in. x 17 in. (13.34 cm x 42.67 cm x 43.18 cm)
Weight Chassis fully configured with a network processing engine or network services engine, I/O
controller, maximum number of port adapters, 2 power supplies, and a fan tray: ~ 50 lb (22.7 kg)
Heat dissipation 370W (1262 BTU
2
)
Chassis fan noise
levels—single speed
fan
Tested:
• Front (I/O controller and port adapter side) 44.2 dB
• Back (power supply side) 43.7 dB
• Left (fan side) 47.2 dB
• Right 44.8 dB
Maximum: 65 dB
Airflow ~80 cfm
3
Temperature 32 to 104•F (0 to 40•C) operating; –4 to 149•F (–20 to 65•C) nonoperatingF (0 to 40•C) operating; –4 to 149•F (–20 to 65•C) nonoperating
Humidity 10 to 90% noncondensing
Power Specifications
AC-input voltage rating 100–240 VAC
4
wide input with power factor correction
AC-input current rating 5A
5
at 100–240 VAC with the chassis fully configured
AC-input frequency
rating
50/60 Hz
6
AC-input cable 18 AWG
7
three-wire cable, with a three-lead IEC-320 receptacle on the power supply end, and a
country-dependent plug on the power source end
DC-output power 280W maximum (with either a single or dual power supply configuration)
DC-input voltage rating –48 VDC
8
nominal in North America
–60 VDC nominal in the European Community
