Page #18 background imageLoading...
Page #18 background image
• Four M4 x 25-mm Phillips-head screws with four anchors
• Two M3 x 7-mm Self-tapping screws
• One 200-mm Ethernet cable
This section describes how to install and remove the ADA nonlockable wall mount kit.
Figure 20: Back View of ADA Non-Lockable Wall Mount Kit Installed on Phone
Wall Mounts
18
Wall Mounts
Non-Lockable Wall Mount Components for 7861
