Cisco 7942G Phone Guide

An Overview of Your Phone
Cisco Unified IP Phone 7962G and 7942G Phone Guide for Cisco Unified Communications Manager 6.1(3) (SCCP and SIP)
Item Description For more information, see...
1
Programmable
buttons
Depending on configuration,
programmable buttons provide access to:
• Phone lines and intercom lines (line
buttons) and intercom lines
• Speed-dial numbers (speed-dial
buttons, including the BLF speed-dial
feature)
• Web-based services (for example, a
Personal Address Book button)
• Call features (for example, a Privacy,
Hold, or Transfer button)
Buttons illuminate to indicate status:
Green, steady—Active call or
two-way intercom call
Green, flashing—Held call
Amber, steady—Privacy in use,
one-way intercom call, DND
active, or logged into Hunt
Group
Amber, flashing—Incoming call
or reverting call
Red, steady—Remote line in use
(shared line or BLF status)
Red, flashing—Remote call on
hold
• Understanding Phone
Screen Features, page 12
• Basic Call Handling,
page 16
• Speed Dialing, page 34
• Using a Shared Line,
page 38
• Using BLF to Determine a
Line State, page 41
• Using BLF to Determine a
Line State, page 41
• Placing or Receiving
Intercom Calls, page 32
2
Phone screen Shows phone features. Understanding Phone Screen
Features, page 12
3
Footstand button Allows you to adjust the angle of the phone
base.
Adjusting the Footstand,
page 5
4
Messages button Auto-dials your voice message service
(varies by service).
Accessing Voice Messages,
page 58
5
Directories button Opens/closes the Directories menu. Use it
to access call logs and directories.
Using Call Logs, page 52
6
Help button Activates the Help menu. Accessing the Help System on
Your Phone, page 13

Cisco 7942G Specifications

General

Lines	2
Audio Codec Support	G.711, G.729a, G.729ab, G.722
Network Protocols	SIP, SCCP
Ethernet Ports	2 x 10/100
Power Options	PoE 802.3af, Optional Power Cube
Speakerphone	Yes
Headset Port	Yes
Weight	3.5 lbs
