Cisco ASR 1000 Series Quick Start Guide

23
Step 7 After the lead wire is fully inserted, hold the lead wire in place by pressing inward while you remove the screwdriver to
release the spring to tension down on the installed lead wire.
Step 8 Once the screwdriver is completely removed, gently pull on the lead wire to make certain that the lead wire is securely
installed.
Figure 21 shows a lead wire fully inserted and the screwdriver removed while you gently pull on the lead to make certain it is
secured in the terminal block.
Figure 21 Removing the Screwdriver from the Cisco ASR 1002-X Router +24V DC Power Supply
Step 9 Repeat Steps 5 through Step 8 for each lead wire. Figure 22 shows the leads wires installed in the terminal block.
1
+24V DC lead ground wire
OUTPUT INPUT
F
A
I
L
OK
O
K
F
AN
T
his
unit
m
ight hav
e
more than
o
ne pow
er s
upply c
on
n
e
c
tion.
All connections m
ust
be
r
em
ov
ed
to de-energize the
unit.
+27V DC INPUT
+2
7V
32A
1
253169

Cisco ASR 1000 Series Specifications

General

Series	ASR 1000
Category	Network Router
Operating System	Cisco IOS XE
Memory	Up to 64 GB
Interfaces	10 Gigabit Ethernet
Power Supply	AC or DC options
Dimensions	Varies by model
Encryption	IPsec, SSL
Storage	Varies by model
Operating Temperature	32°F to 104°F (0°C to 40°C)
Humidity	5% to 95% non-condensing
MTBF	Varies by model
