Cisco ASR 1000 Series Quick Start Guide

27
Table 4 provides information about the Cisco ASR1000-ESP5 LEDs in the Cisco ASR 1002-X Router as the system starts.
Table 4 Cisco ASR1000-ESP5 and ASR1000-ESP10 LED Activity
During the boot process, observe the system LEDs. The STATUS LED comes on immediately as amber, then turns to green when
the Cisco IOS is booted.
Note The system boots differently depending on the configuration that ships with your system. The display below is a
snapshot of messages that are output on the console of the Cisco ASR 1002-X Router system after power-up and during
IOS booting. This is only an example of what you might see from any Cisco ASR 1000 Series Router.
MAJ Major Solid red Major alarm indicator.
MIN Minor Amber Minor alarm indicator.
LINK 10/100/1000 RJ-45 Flashing green Link activity indicator.
Off No link.
Solid green Link with no activity.
BOOT eUSB FLASH
BOOT (BootDisk)
Flashing green Activity indicator.
Off No activity.
CARRIER BITS Green In frame and working properly.
Off Out of service or not configured.
Amber Fault or loop condition.
**Built-in
6xGE SPA SFP
Port Status
4 LEDs total, one for each
SFP
Off Port is not enabled.
Amber Port enabled. Problem with the Ethernet link.
Green Port enabled and the Ethernet link is valid.
CC - PWR Embedded SIP power rail
status
Green If all power supplies within their tolerance specifications.
CC - STAT Embedded SIP current status Green Green only when the SPA drivers have started and are
running and all critical processes are running.
Yellow ROMMON is running and during the download and
boot.
Red A fault is detected or the card is powering up.
**For more information about the small form-factor pluggable (SFP) transceiver modules that are compatible with Cisco ASR 1002-X Built-in
Gigabit Ethernet Ports (6x1GE), refer to the Modular Optics Compatibility section in the Cisco ASR 1000 Series Aggregation Services Routers
SIP and SPA Hardware Installation Guide.
LED Label LED Color Behavior Description
PWR Power Solid green All power supplies are within operational limits.
Off The router is in standby mode.
STAT Status Green Code has successfully downloaded and is operational.
Yellow BOOT ROM has successfully loaded.
Red Not booted.
ACTV Active Green The embedded services processor is green when active.
STBY Standby None Will always be off.
LED Label LED Color In the Power Up State -Behavior Description
