Cisco ASR 1002-X Overview And Installation

Ground lead8Power supply switch Standby/On (|)3
Positive lead9Power supply LEDs4
Negative lead10Fan5
The following table lists the Cisco ASR 1002-X Router –48 VDC power supply LEDs.
Table 3: Cisco ASR 1002-X Router –48 VDC Power Supply LEDs
DescriptionColorLEDLED Label
The LED turns green to signal that the DC power supply input voltage is greater
than 43.5VDC at turn-on and remains green until the level of 39 VDC is reached.
GreenA bi-color LED
indicates the presence
of input voltage
INPUT OK
The LED turns amber if the power supply turns off due to low input voltage (falls
below 39VDC) and indicates that a hazard (voltage on the terminal block) is still
present. The LED remains amber and is active until around 20 V +/-5 V. If the
input is below 15 V, the LED is not illuminated
Amber
The LED turns green when all fans are operational.Green
A bi-color LED
indicates power
supply fan status
FAN OK
The LED turns red when a fan failure is detected.Red
When the LED is off, it signals that the DC output voltage is within the normal
operating range. Output voltage between the minimum limit and maximum limit
will not create an Output Fail alarm, but output voltages below the minimum limit
or above the maximum limit will create an Output Fail alarm.
Led turns red to indicate that the DC output is out of the specified range.
When you turn on the power supply, the LED turns red for two to three seconds to
test the LED operation before going off.
Red
Power supply activityOUTPUT
FAIL
The output voltage alarm is raised when the output voltage is below the low end of the minimum limit or
above the high end of the maximum limit. When the output voltage is above the high end of the minimum or
below the low end of the maximum limit, the red state is not activated.
The following table shows the –48 VDC power supply output voltage alarm ranges.
Table 4: –48 VDC Power Supply Output Voltage Alarm Threshold Ranges
MaximumMinimumOutput
12.8-13.8 V10.0-11.2 V12 V
None2.6-3.0 V3.3 V
+24 VDC Power Supply for the Cisco ASR 1002-X Router
This section provides information about the +24 VDC power supply at the rear of the Cisco ASR 1002-X
Router. The recommended branch circuit breaker for the Cisco ASR 1002-X Router +24 VDC power supply
is a 40 A UL-listed circuit breaker.
