Cisco ASR 1002 Replacing

During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly touch
the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Warning
Before you begin, read the following important notices:
• The form-factor internal hard drive is accessible from the front panel of the Cisco ASR1000-RP2 and
supports the online insertion and removal feature (OIR) using the following CLI commands for the
standby and active RP2:
• request platform hardware filesystem harddisk: offline (Unmounts the hard disk on the active
RP2.)
• request platform hardware filesystem harddisk: online (Mounts the hard disk on the active RP2.)
If the disk is not provisioned properly, this command will provision the disk.
• request platform hardware filesystem stby-harddisk: offline (Unmounts the hard disk on the
standby RP2.)
• requestplatform hardware filesystem stby-harddisk: online (Mounts the hard disk on the standby
RP2. If the disk is not provisioned properly, this command will provision the disk.)
• The reason you would be removing an internal hard drive is that it is failing or failed; so any data recovery
may be lost.
• If the drive is functioning, you can back it up to a drive plugged into a USB port using the archive tar
command.
Removing the Cisco ASR1000-RP2 Internal Hard Drive
To remove the Cisco ASR1000-RP2 internal hard drive from the Cisco ASR 1006 Router and Cisco ASR
1004 Router, follow this procedure:
SUMMARY STEPS
1. Run the request platform hardware filesystem harddisk: offline command.
2. Slip on an ESD-preventive wrist strap.
3. From the front panel of the Cisco ASR1000-RP2, unscrew the fastener screw (see the following figure).
4. Pull the internal hard drive out as shown in the following figure.
5. Place the component in an antistatic bag if you are returning it.
6. Wait until the following console message is displayed:
DETAILED STEPS
Step 1 Run the request platform hardware filesystem harddisk: offline command.
Step 2 Slip on an ESD-preventive wrist strap.
Step 3 From the front panel of the Cisco ASR1000-RP2, unscrew the fastener screw (see the following figure).
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
10
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing the Cisco ASR1000-RP2 Internal Hard Drive

Cisco ASR 1002 Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
DHCP client	-
Supported network protocols	BGP, GRE, OSPF, DVMRP, EIGRP, IS-IS, IGMPv3, PIM-SM, PIM-SSM
Ethernet LAN (RJ-45) ports	4
Security algorithms	SSH
VPN tunnels quantity	8000
Safety	UL60950-1 CSA, C22.2 No. 60950-1-03, EN 60950-1, IEC 60950-1, AS/NZS 60950.1
Certification	FCC 47CFR15 Class A AS/NZS CISPR 22 CISPR 22 Class A EN55022 Class A ICES-003 Class A VCCI Class A CNS-13438 Class A EN61000-3-2 EN61000-3-3
Internal memory	4096 MB
AC input voltage	85 - 264 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	560 W
Operating altitude	0 - 3048 m
Storage temperature (T-T)	0 - 50 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Product color	Gray
Rack capacity	2U

Weight and Dimensions

Depth	461 mm
Width	437.4 mm
Height	89 mm
Weight	- g
