Page #89 background imageLoading...
Page #89 background image
When securing the ground, positive, and negative –48 VDC-input leads to the power supply faceplate, leave
extra service loop in the ground lead to ensure that the ground lead is the last lead to disconnect from the power
supply if a great deal of strain is placed on all three leads as shown in xref fig.
Caution
Step 7 Turn on the branch source breaker.
Step 8 Place the power supply standby switch to the On (|) position. The power supply LEDs light when power is supplied to
the router.
Removing and Replacing a +24 VDC Power Supply in Cisco ASR 1002 Router
This section provides information about removing and replacing a +24 VDC power supply in the Cisco ASR
1002 Router.
Before you begin, read the following notices:
The labeling displays +27 VDC INPUT. This labeling describes the nominal voltage provided at a cell
site.
Observe the polarity location—Unlike the polarity labels of the –48 VDC power supply (ground, positive,
negative), the polarity labels on the +24 VDC are ground, negative, positive as shown in xref fig from
right to left as they appear on the actual power supply unit.
The ground (GND) lead is always installed first and removed last.
The +24 VDC power supply uses a spring loaded terminal block; therefore have the recommended
screwdriver size available.
Review the diagrams to see how the wire is stripped and how the screwdriver is inserted at an angle into
the terminal block.
Have the following equipment available to install and remove the +24 VDC power supply:
Phoenix Contact 3.5mm flat-blade screwdriver or equivalent
Wire-stripping tool for stripping 8-gauge wire
When you install the unit, the ground connection must always be made first and disconnected last. Statement
1046
Warning
Before performing any of the following procedures, ensure that power is removed from the DC circuit.
Statement 1003
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
89
Removing and Replacing FRUs from the Cisco ASR 1000 Series Routers
Removing and Replacing a +24 VDC Power Supply in Cisco ASR 1002 Router
