Cisco ASR 9000 Series Configuring

Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-330
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Step 9
controller controllerName instance
Example:
RP/0/RSP0/CPU0:router(config)# controller
t3 0/1/1/0/0
Enters controller configuration submode and specifies the
controller name and instance identifier with the
rack/slot/module/port/controllerName notation. The controller
names are:
• t3—SONET path carrying T3
• vt15-t1—SONET path carrying virtual tributary 1.5 T1s
(VT15 T1) (1-Port Channelized OC-3/STM-1 SPA and 2-Port
Channelized OC-12c/DS0 SPA only)
Step 10
mode mode
Example:
RP/0/RSP0/CPU0:router(config-t3)# mode t1
Sets the mode of interface at this level. The possible modes are:
• t1—Channelized into 28 T1s (1-Port Channelized
OC-3/STM-1 SPA and 2-Port Channelized OC-12c/DS0 SPA
only)
• e1—Channelized into 21 E1s (1-Port Channelized
OC-3/STM-1 SPA and 2-Port Channelized OC-12c/DS0 SPA
only)
• serial—Clear channel carrying an HDLC-like payload
Step 11
root
Example:
RP/0/RSP0/CPU0:router(config-t3)# root
Exits to global configuration mode.
Step 12
controller t1 interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# controller
t1 0/1/1/0/0/0
Enters T1 controller configuration submode and specifies the T1
controller name and interface-path-id with the
rack/slot/module/port/T3Num/T1num notation.
(1-Port Channelized OC-3/STM-1 SPA and 2-Port Channelized
OC-12c/DS0 SPA only)
Step 13
channel-group number
Example:
RP/0/RSP0/CPU0:router(config-t1)#
channel-group 1
Sets the channel group number to which time slots are assigned.
The range is from 1 to 24.
Step 14
timeslots num1:num2:num3:num4
or
timeslots range1-range2
Example:
RP/0/0/CPU0:router(config-t1-channel_grou
p)# timeslots 1:3:7:9
RP/0/0/CPU0:router(config-t1-channel_grou
p)# timeslots 1-24
Specifies the time slots for the interface by number with the
num1:num2:num3:num4 notation, or by range with the
range1-range2 notation.
Step 15
show configuration
Example:
RP/0/RSP0/CPU0:router(config-t1-channel_g
roup)# show configuration
Displays the contents of uncommitted configuration.
Command or Action Purpose
