Cisco ASR 9000 Series Configuring

Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
Configuration Examples for Channelized SONET
HC-356
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Channelized SDH Examples
• Channelized SDH AU-3 Configuration: Examples, page 356
• Channelized SDH AU-4 Configuration: Examples, page 357
Channelized SDH AU-3 Configuration: Examples
This section includes the following configuration examples:
• Channelized SDH AU-3 to VC-3 and Clear Channel T3/E3: Examples, page 356
• Channelized SDH AU-3 to TUG-2, VC-11, T1 and NxDS0s: Example, page 356
• Channelized SDH AU-3 to TUG-2, VC-12, E1 and NxDS0s: Example, page 357
Channelized SDH AU-3 to VC-3 and Clear Channel T3/E3: Examples
The following example shows how to configure SDH AU-3 to VC-3 and clear channel T3:
configure
controller sonet 0/1/1/0
clock source internal
framing sdh
au 1
width 1
mode t3
root
controller t3 0/1/1/0/1
mode serial
commit
The following example shows how to configure SDH AU-3 to VC-3 and clear channel E3:
configure
controller sonet 0/1/1/0
clock source internal
framing sdh
au 1
width 1
mode e3
root
controller e3 0/1/1/0/1
mode serial
commit
Channelized SDH AU-3 to TUG-2, VC-11, T1 and NxDS0s: Example
Note This example is not supported on the 1-Port Channelized OC-48/STM-16 SPA.
The following example shows how to configure SDH AU-3 to TUG-2, VC-11 and channelized T1 to
NxDS0s:
configure
controller sonet 0/1/1/0
clock source internal
framing sdh
au 1
