Cisco ASR 9000 Series Configuring

Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
Configuration Examples for Channelized SONET
HC-357
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
mode c11-t1
width 1
root
controller T1 0/1/1/0/0/1/1
channel-group 0
timeslots 1-12
show configuration
root
interface serial 0/1/1/0/1/1:0
encapsulation ppp
ip address 10.10.10.10 255.255.255.255
no shutdown
commit
show controllers sonet 0/1/1/0
Channelized SDH AU-3 to TUG-2, VC-12, E1 and NxDS0s: Example
Note This example is not supported on the 1-Port Channelized OC-48/STM-16 SPA.
The following example shows how to configure SDH AU-3 to TUG-2, VC-12 and channelized E1 to
NxDS0s:
configure
controller sonet 0/1/1/0
clock source internal
framing sdh
au 1
mode c12-e1
width 1
root
controller e1 0/1/1/0/0/1/1
channel-group 0
timeslots 1-12
show configuration
root
interface serial 0/1/1/0/1/1:0
encapsulation ppp
ip address 10.10.10.10 255.255.255.255
no shutdown
commit
show controllers sonet 0/1/1/0
Channelized SDH AU-4 Configuration: Examples
This section includes the following configuration examples:
• Channelized SDH AU-4 to TUG-3 and Clear Channel T3/E3: Examples, page 357
• Channelized SDH AU-4 to TUG-3, TUG-2, and T1/E1 and NxDS0: Examples, page 358
Channelized SDH AU-4 to TUG-3 and Clear Channel T3/E3: Examples
The following exampe shows SDH AU-4 channelization to TUG-3 and clear channel T3:
configure
controller sonet 0/4/0/0
framing sdh
au 1
width 3
