Cisco ASR 9000 Series Configuring

Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-342
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Restrictions
Channelized SDH AU-3 with c11-t1 or c12-e1 mapping is supported on the following SPAs:
• Cisco 1-Port Channelized OC-3/STM-1 SPA
• Cisco 2-Port Channelized OC-12c/DS0 SPA
SUMMARY STEPS
1. configure
2. controller sonet interface-path-id
3. clock source {internal | line}
4. framing sdh
5. au number
6. mode mode
7. root
8. controller t1 interface-path-id
9. channel-group number
10. timeslots num1:num2:num3:num4
or
timeslots range1-range2
11. show configuration
12. root
13. interface serial interface-path-id
14. encapsulation {frame-relay | hdlc | ppp}
15. ipv4 ip-address mask
16. no shutdown
17. end
or
commit
18. show controllers sonet interface-path-id
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
controller sonet interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# controller
sonet 0/1/1/0
Enters SONET controller configuration submode and specifies the
SONET controller name and interface-path-id identifier with the
rack/slot/module/port notation.
