Cisco ASR 9000 Series Configuring

Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
How to Configure Channelized SONET/SDH
HC-346
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
4. framing sdh
5. au number
6. mode t3
or
mode e3
7. root
8. controller {t3 | e3} interface-path-id
9. mode serial
10. show configuration
11. root
12. interface serial interface-path-id
13. encapsulation {frame-relay | hdlc | ppp}
14. ipv4 ip-address mask
15. no shutdown
16. end
or
commit
17. show controllers sonet interface-path-id
DETAILED STEPS
Command or Action Purpose
Step 1
configure
Example:
RP/0/RSP0/CPU0:router# configure
Enters global configuration mode.
Step 2
controller sonet interface-path-id
Example:
RP/0/RSP0/CPU0:router(config)# controller
sonet 0/1/1/0
Enters SONET controller configuration submode and specifies the
SONET controller name and interface-path-id identifier with the
rack/slot/module/port notation.
Step 3
clock source {internal | line}
Example:
RP/0/RSP0/CPU0:router(config-sonet)#
clock source internal
Configures the SONET port transmit clock source, where the
internal keyword sets the internal clock and the line keyword sets
the clock recovered from the line.
• Use the line keyword whenever clocking is derived from the
network. Use the internal keyword when two routers are
connected back to back or over fiber for which no clocking is
available.
• line is the default keyword.
Note Internal clocking is required for SRP interfaces.
