Configuring Channelized SONET/SDH on the Cisco ASR 9000 Series Router
Information About Configuring Channelized SONET/SDH
HC-322
Cisco ASR 9000 Aggregation Services Router Interfaces and Hardware Component Configuration Guide
OL-26061-03
Figure 24 shows the T3 paths that can be configured.
Note Channelized T3 paths are only supported on the 1-Port Channelized OC-3/STM-1 SPA and 2-Port
Channelized OC-12c/DS0 SPA.
Figure 24 SONET T3 Channelized Paths
STS 3
SONET
Controller
. . . same possibilities as STS 1
STS 2
. . . same possibilities as STS 1
STS 1
210876
DS0
DS0
DS0
DS0
DS0
DS0
DS0
DS0
DS0
. . . up to 24 DS0s
T1
T1
T1
T1
T1
T1
T1
T1
T1
T3
T3
T3
. . . up to 28 T1s
. . .
. . .
. . .
. . .
. . .
. . .
. . .
. . .
