Cisco ASR 9010 Unpacking And Installing

Figure 43: Removing a Line Card from the Cisco ASR 9922 Router Top Card Cage
Slide the card out of
the chassis.
cPivot the ejector
levers outward to
unseat the card from
the backplane
connector.
bLoosen the captive
screws.
a
Unpacking and Installing the Chassis
47
Unpacking and Installing the Chassis
Removing RP Cards, Fabric Cards, and Line Cards from the Cisco ASR 9922 Router and Cisco ASR 9912 Router

Cisco ASR 9010 Specifications

General

Chassis	Modular
Rack Units	21 RU
Operating System	Cisco IOS XR
Form Factor	Rack-mountable
Number of Slots	10
Power Supply	AC or DC
Redundancy	Yes
Slots	8 line card slots, 2 route switch processor slots
Memory	16 GB DRAM
Storage	64 GB SSD (Route Processor)
Port Types	Ethernet, OTN
Redundancy Features	Route Processor, Power Supply, Fan Tray
Operating Temperature	32 to 104°F (0 to 40°C)
Humidity	5% to 90% non-condensing
Route Processor	Cisco ASR 9000 Series Route Switch Processor
