Cisco ASR 9010

Figure 48: Installing the Cisco ASR 9006 Router Chassis in a Standard 2-Post Rack
Four screws per side (minimum) to attach the router
chassis to the rack.
1
The figure below shows the orientation of the Cisco ASR 9904 Router chassis to the rack posts and components
used in the installation.
Unpacking and Installing the Chassis
52
Unpacking and Installing the Chassis
Installing the Chassis in a 2-Post Rack
