Connecting to the EIA Console Port
The USB-to-RJ45 adapter cable and the DB9 console cable are not included with the Cisco
ASR-920-10SZ-PD Router; they can be ordered separately from Cisco.
Note
The serial console cable kit is not included with the Cisco ASR-920-10SZ-PD Router; it is ordered
separately.
Note
To connect a terminal to the EIA Console port on the router, follow these steps:
SUMMARY STEPS
1.
Connect the USB end of the USB-to RJ-45 cable to the EIA Console port.
2.
Connect the RJ-45 end of the DB-9 adapter cable to the USB-to RJ-45 cable, as shown in figure below.
3.
Connect the DB-9 end of the console cable to the DB-9 end of the terminal.
4.
To communicate with the router, start a terminal emulator application, such as Microsoft Windows
HyperTerminal. This software should be configured with the following parameters:
Cisco ASR 920-10SZ-PD Aggregation Services Router Hardware Installation Guide
24
Installing the Cisco ASR-920-10SZ-PD Router
Connecting to the EIA Console Port
