1-3
Cisco Aironet 1000 Series Lightweight Access Point Hardware Installation Guide
OL-9403-04
Chapter 1 Overview
Hardware Features
Figure 1-1 Access Point Configurations
Figure 1-2 illustrates the left side connectors on the access point.
Figure 1-2 Access Point Left Side Connectors
1 Integrated antennas only (AIR-AP1010) 2 Integrated antennas and external antenna
connectors (AIR-AP1020 and AIR-AP1030)
146971
1 2
5 GHz
2.4 GHz
Alarm
Power
5 GHz
2.4 GHz
Alarm
Power
1 Security key slot 3 48-VDC power port
2 2.4-GHz antenna connector (left) 4 Ethernet port (RJ-45)
146973
24 GHz Left
48 v
250Ma
Ethernet
2
1
3 4
