Chapter 3 Troubleshooting
Checking the Access Point LEDs
Checking the Access Point LEDs
If your access point is not working properly, check the access point LEDs on the top of the unit. You can
use the LED indications to quickly assess the unit’s status. Figure 3-1 shows the access point LEDs (for
additional information refer to the Event Log using the access point browser interface).
Figure 3-1 Access Point LEDs
1 5-GHz LED 3 Alarm LED
2 2.4-GHz LED 4 Power LED
146972
1 2 3 4
5 GHz 2.4 GHz Alarm Power
side A
