Cisco Catalyst 3850 User Manual

CONTENTS
Preface xi
PREFACE
Document Conventions xi
Related Documentation xiii
Obtaining Documentation and Submitting a Service Request xiii
Product Overview 1
CHAPTER 1
Switch Models 1
Front Panel 6
10/100/1000 Ports 8
PoE, PoE+, and Cisco UPoE Ports 8
SFP and QSFP Module Slots 9
Management Ports 9
USB Type A Port 10
Network Modules 11
SFP and SFP+ Modules 13
LEDs 13
SYST LED 16
XPS LED 16
Port LEDs and Modes 17
USB Console LED 19
S-PWR LED 19
ACTV LED 20
STACK LED 20
PoE LED 21
UID/Beacon LED 21
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-05ii
Contents

Cisco Catalyst 3850 Specifications

General

Stacking Bandwidth	480 Gbps
Max Stacking Units	9
Form Factor	Rack-mountable
RAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3850
Ports	24 or 48 Gigabit Ethernet ports
Uplink Interfaces	4 x 1GE, 2 x 10GE, or 4 x 10GE
Power Supply	Redundant power supplies
Dimensions	44.5 x 44.8 x 4.45 cm
Weight	7.6 kg
Features	IPv6
Power over Ethernet (PoE)	PoE, PoE+, UPOE (varies by model)
Operating Temperature	0 to 40°C
