Power supply FAIL LED6CONSOLE (RJ-45
console port)
2
Power supply OK LED7BEACON LED3
Power supply modules8MGMT (RJ-45
10/100/1000 management
9 AC OK (input) status
LED port)
4
RJ-45 Console Port LED
Table 12: RJ-45 Console Port LED
RJ-45 Console Port StatusColor
RJ-45 console is disabled. USB console is active.Off
RJ-45 console is enabled. USB console is disabled.Green
StackWise Ports
StackWise ports are used to connect switches in StackWise stacking configurations. The switch ships with a
0.5-meter StackWise cable that you can use to connect the StackWise ports. For more information on StackWise
cables, see Connecting to the StackWise Ports, on page 47.
The following switch models do not support StackWise-480:
WS-C3850-48XS-S
WS-C3850-48XS-E
WS-C3850-48XS-F-S
WS-C3850-48XS-F-E
Note
Use only approved cables, and connect only to similar Cisco equipment. Equipment might be damaged if
connected to nonapproved Cisco cables or equipment.
Caution
Power Supply Modules
The switches are powered through one or two internal power supply modules.
Supported power supply modules:
PWR-C1-350WAC
Catalyst 3850 Switch Hardware Installation Guide
25OL-26779-05
Product Overview
RJ-45 Console Port LED
