DescriptionNetwork Module
5
This module has four slots:
Two slots (left side) support only 1 G SFP modules and two slots (right side)
support either 1 G SFP or 10 G SFP modules.
This is supported on the following switch models:
Note
• WS-C3850-24T/P/U
• WS-C3850-48T/F/P/U
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-12S
• WS-C3850-24S
C3850-NM-2-10G
This module has four 10 G slots or four 1 G slots.
This is supported on the following switch models:
Note
• WS-C3850-48T/F/P/U
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-12XS
• WS-C3850-24XS
C3850-NM-4-10G
This module has eight 10 G slots with an SFP+ port in each slot. Each port
supports a 1 G or 10 G connection
This is supported on the following switch models:
Note
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-24XS
C3850-NM-8-10G
This module has two 40 G slots with a QSFP+ connector in each slot.
This is supported on the following switch models:
Note
• WS-C3850-12X48U
• WS-C3850-24XU
• WS-C3850-24XS
C3850-NM-2-40G
Insert this blank module when the switch has no uplink ports (this is required for
sufficient air flow).
C3850-NM-BLANK
Catalyst 3850 Switch Hardware Installation Guide
OL-26779-0512
Product Overview
Network Modules

Cisco Catalyst 3850 Specifications

General

Stacking Bandwidth	480 Gbps
Max Stacking Units	9
Form Factor	Rack-mountable
RAM	4 GB
Flash Memory	4 GB
Operating System	Cisco IOS XE
Model	Catalyst 3850
Ports	24 or 48 Gigabit Ethernet ports
Uplink Interfaces	4 x 1GE, 2 x 10GE, or 4 x 10GE
Power Supply	Redundant power supplies
Dimensions	44.5 x 44.8 x 4.45 cm
Weight	7.6 kg
Features	IPv6
Power over Ethernet (PoE)	PoE, PoE+, UPOE (varies by model)
Operating Temperature	0 to 40°C
