Cisco Catalyst 9600 Series User Manual

APPENDIX B
LEDs
• Fan Tray LEDs, on page 97
• Power Supply Modules LEDs, on page 97
• Supervisor Module LEDs, on page 98
• Line Card LEDs, on page 99
Fan Tray LEDs
MeaningLED Position or ColorLED Type
Fan tray is not getting any power.Off
STATUS
All fans are running and the fan tray is operating
normally.
Green
One fan is not running.Amber
Two or more fans are not running.Red
Identifies the fan tray receiving the beacon signal.
The fan tray assembly has two blue beacon LEDs, one
on the front panel and one on the rear. The two will
always match each other.
The blue beacon LED on the front panel is also a switch
that you can press, to turn the front and rear blue beacons
on or off. Alternatively, you can turn the blue beacons
on or off through software.
Blue
LOCATE
Power Supply Modules LEDs
MeaningLED Position or Colour
Indicates that the power supply module is switched on with outputs
12V main and 12Vstandby available and in regulation.
Solid Green
Cisco Catalyst 9600 Series Switches Hardware Installation Guide
97

Cisco Catalyst 9600 Series Specifications

General

Series	Catalyst 9600 Series
Category	Switch
Switching Capacity	Up to 25.6 Tbps
Software	Cisco IOS XE
Form Factor	Modular chassis
Purpose	Enterprise campus core and distribution
Ports	10G, 25G, 40G, 100G, 400G
Redundancy	Yes, supports redundant power supplies and fans
Stacking	Virtual Stacking supported
Security	Advanced security features including MACsec encryption
Management	Cisco DNA Center, CLI, SNMP
Uplink Ports	40G, 100G
Power Supply	Redundant, hot-swappable
Operating Temperature	0°C to 45°C (32°F to 113°F)
Port Density	Up to 384 ports
Weight	Starting at 75 lbs (34 kg)
Modular Slots	Up to 6 line card slots
