Cisco Catalyst C9300-48P User Manual

Figure 11: Rear Panel of a Cisco Catalyst 9300L Series Switch
USB3.0 SSD port5CONSOLE (RJ-45 console port)1
Power supply modules6BEACON LED2
StackWise-320 port connectors7MGMT (RJ-45 10/100/1000 management
port)
3
--Fan modules4
Figure 12: Rear Panel of a Cisco Catalyst 9300LM Series Switch
Power supply modules4Ground connectors1
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
23
Product Overview
Rear Panel

Cisco Catalyst C9300-48P Specifications

General

Model	C9300-48P
Ports	48x 10/100/1000 PoE+ ports
Switching Capacity	176 Gbps
Stacking Bandwidth	480 Gbps
Stackable	Yes
DRAM	8 GB
Flash Memory	16 GB
Power Device	Internal power supply
Uplink Interfaces	4 x 10G
Power Supply	715W AC
Dimensions	1.73 x 17.5 x 17.5 inches
Input Voltage	100 to 240 VAC
Operating Temperature	32 to 104°F (0 to 40°C)
