Chapter 1 Migrating to a Cisco CRS-3 Carrier Routing System
How to Migrate to a Cisco CRS-3 Carrier Routing System (8-Slot)
Example
The following example shows commands to disable power to the CRS-1 Fabric Card:
RP/0/RP0/CPU0:router#admin
RP/0/RP0/CPU0:router(admin)#config
RP/0/RP0/CPU0:router(admin-config)#hw-module power disable loc 0/SM0/SP
RP/0/RP0/CPU0:router(admin-config)#commit
RP/0/RP0/CPU0:router(admin)#show platform
Node Type PLIM State Config State
<snip>
0/SM0/SP FC/S(SP) N/A UNPOWERED PWR,NSHUT,MON
0/SM1/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
0/SM2/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
0/SM3/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
0/SM4/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
0/SM5/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
0/SM6/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
0/SM7/SP FC/S(SP) N/A IOS XR RUN PWR,NSHUT,MON
<snip>
What to Do Next
Next we physically remove the CRS-1 fabric card.
Physically Removing the CRS-1 Fabric Card
This section describes how to physically remove the CRS-1 fabric card, and verify that node is ready to
have a CRS-3 fabric card installed in its place.
This section describes how to remove a CRS-1 fabric card from the Cisco CRS Fabric Card Chassis. For
more detailed information on the switch fabric card, see Cisco CRS Carrier Routing System 8-Slot Line
Card Chassis System Description.
Caution Class 1M laser radiation when open. Do not view directly with optical instruments. Statement 281
Step 5
end
Example:
RP/0/RP1/CPU0:router(admin-config)# end
Changes the mode from administration configuration mode
to administration EXEC mode.
Step 6
show platform
Example:
RP/0/RP0/CPU0:router(admin)#show platform
Displays the power status of all eight fabric planes.
• Verify that the fabric card in node 0/SM0/SP is in the
UNPOWERED state.
Command or Action Purpose
