Redirecting Subscriber Traffic Using ISG Layer 4 Redirect
How to Configure ISG Layer 4 Redirect
8
DETAILED STEPS
Examples
The following example shows sample output for the show redirect translations command:
Router# show redirect translations ip 10.53.0.2
Destination IP/port Server IP/port Prot In Flags Out Flags Timestamp
172.20.0.2 23 10.2.36.253 23 TCP none none May 08 2003
12:37:10
The following example shows sample output for the show subscriber session command. This output
shows that Layer 4 redirect is being applied from the service profile.
Router# show subscriber session uid 135
Subscriber session handle: 7C000114, state: connected, service: Local Term
Unique Session ID: 135
Identifier: blind-rdt
SIP subscriber access type(s): IP-Interface
Root SIP Handle: CF000020, PID: 73
Current SIP options: Req Fwding/Req Fwded
Session Up-time: 40 minutes, 30 seconds, Last Changed: 40 minutes, 30 seconds
AAA unique ID: 135
Switch handle: F000086
Interface: ATM2/0.53
Policy information:
Authentication status: unauthen
Config downloaded for session policy:
From Access-Type: IP-Interface, Client: SM, Event: Service Selection Request, Service
Profile name: blind-rdt, 2 references
username "blind-rdt"
l4redirect "redirect to group sesm-grp"
Rules, actions and conditions executed:
Command or Action Purpose
Step 1
enable
Example:
Router> enable
Enables privileged EXEC mode.
• Enter your password if prompted.
Step 2
show redirect translations [ip ip-address]
Example:
Router# show redirect translations ip 10.0.0.0
Displays ISG Layer 4 redirect translations for sessions.
Step 3
show redirect group [group-name]
Example:
Router# show redirect group redirect1
Displays information about ISG redirect server groups.
Step 4
show subscriber session [detailed] [identifier
identifier | uid session-id | username name]
Example:
Router# show subscriber session detailed
Displays ISG subscriber session information.
