Implementing IPSec Network Security on Cisco IOS XR Software
Restrictions for Implementing IPSec Network Security
SC-93
Cisco IOS XR System Security Configuration Guide
Restrictions for Implementing IPSec Network Security
If you use Network Address Translation (NAT), you should configure static NAT translations so that
IPSec will work properly. In general, NAT translation should occur before the router performs IPSec
encapsulation; in other words, IPSec should be working with global addresses.
Note You should be using static crypto profiles.
Restrictions for Implementing IPSec Network with a
Cisco IPSec VPN SPA
The following restrictions are known to implement IPSec network with a Cisco XR 12000 Series Router
IPSec VPN SPA:
• Clear GRE is not supported. Only secure generic routing encapsulation (GRE) is supported by the
Cisco XR 12000 Series Router IPSec VPN SPA. To configure the Cisco XR 12000 Series Router
IPSec VPN SPA, you can use either service-ipsec or service-gre interfaces.
• Dynamic virtual interfaces are not supported.
• Dynamic Multipoint VPN (DMVPN) is not supported.
• Multicast is supported on interfaces in global VRF.
The following restrictions are known when implementing IPSec with the Cisco XR 12000 Series Router
IPSec VPN SPA for Internet Security Association Key Management Protocol (ISAKMP) and IPSec
profile configurations:
• One IPSec profile is configured on a virtual interface (for example, service ipsec or service-gre). A
profile has one or more access control lists (ACLs). Each ACL has one or more access control entry
(ACE). ACLs and ACEs cannot intersect.
• With both tunnel source and tunnel destination defined, a dynamic profile configuration on a virtual
interface is rejected.
• Multiple virtual interfaces are attached to ISAKMP profiles; however, a virtual interface is
referenced from a single ISAKMP profile only. The constraint is required to uniquely identify the
virtual interface, ISAKMP profile, and IPSec profile as an IKE initiator and IKE responder.
The following restrictions are known to implement Cisco XR 12000 Series Router IPSec VPN SPA for
the tunnel source address:
• Virtual interfaces that use the same tunnel source and FVRF are configured on the same
Cisco XR 12000 Series Router IPSec VPN SPA.
• When NAT traversal is active for two tunnels that share the same source and destination address and
FVRF under two different virtual interfaces, IP packets that require fragmentation are dropped.
