Cisco IOS XR User Manual

Implementing IPSec Network Security on Cisco IOS XR Software
How to Implement IPSec Network Security for VPNs
SC-137
Cisco IOS XR System Security Configuration Guide
Step 5
tunnel destination ip-address
Example:
RP/0/0/CPU0:router(config-if)# tunnel destination
172.19.72.120
Identifies the IP address of the tunnel destination.
• Use the ip-address argument to set the IP
address of the host destination.
If dynamic, the destination IP address is optional.
Step 6
tunnel vrf vrf-name
Example:
RP/0/0/CPU0:router(config-if)# tunnel vrf internet
Associates a VRF instance with the tunnel source or
destination of the interfaces. The tunnel VRF
specifies in which VRF the tunneled traffic is
forwarded (FVRF). Tunnel VRF is not required if
FVRF is the global VRF.
• Use the vrf-name argument to assign the name
of a VRF.
Step 7
vrf vrf-name
Example:
RP/0/0/CPU0:router(config-if)# vrf vpn_a
Assigns a VRF to the interface. VRF is specified to
clear traffic that is forwarded for the internal VRF
(IVRF). In addition, VRF is not required if IVRF is
a global VRF.
• Use the vrf-name argument to assign the name
of a VRF.
Step 8
ipv4 address ipv4-address mask [secondary]
Example:
RP/0/0/CPU0:router(config-if)# ipv4 address
192.168.1.27 255.255.255.0
Sets a primary or secondary IPv4 address for an
interface, for example, a POS interface.
• Use the ipv4-address argument to set the IPv4
address.
• Use the mask argument to set the mask for the
associated IP subnet. The network mask is
specified in either of two ways:
– The network mask is a four-part dotted
decimal address. For example, 255.0.0.0
indicates that each bit equal to 1 means that
the corresponding address bit belongs to the
network address.
– The network mask is indicated as a slash (/)
and number. For example, /8 indicates that
the first 8 bits of the mask are ones, and the
corresponding bits of the address are the
network address.
• (Optional) Use the secondary keyword to
specify that the configured address is a
secondary IPv4 address. If this keyword is
omitted, the configured address is the primary
IPv4 address.
