Cisco IOS XR User Manual

Implementing Internet Key Exchange Security Protocol on Cisco IOS XR Software
Configuration Examples for Implementing IKE Security Protocol
SC-69
Cisco IOS XR System Security Configuration Guide
Creating IKE Policies: Example
This example shows how to create two IKE policies with policy 15 as the highest priority, policy 20 as
the next priority, and the existing default priority as the lowest priority.
crypto isakmp policy 15
encryption 3des
hash md5
authentication rsa-sig
group 2
lifetime 5000
crypto isakmp policy 20
authentication pre-share
lifetime 10000
In the example, the encryption des of policy 15 would not appear in the written configuration because
this is the default value for the encryption algorithm parameter.
If the show crypto isakmp policy command is issued with this configuration, the output is as follows:
Protection suite priority 15
encryption algorithm:DES - Data Encryption Standard (56 bit keys)
hash algorithm:Message Digest 5
authentication method:Rivest-Shamir-Adelman Signature
Diffie-Hellman group:#2 (1024 bit)
lifetime:5000 seconds, no volume limit
Protection suite priority 20
encryption algorithm:DES - Data Encryption Standard (56 bit keys)
hash algorithm:Secure Hash Standard
authentication method:preshared Key
Diffie-Hellman group:#1 (768 bit)
lifetime:10000 seconds, no volume limit
Default protection suite
encryption algorithm:DES - Data Encryption Standard (56 bit keys)
hash algorithm:Secure Hash Standard
authentication method:Rivest-Shamir-Adelman Signature
Diffie-Hellman group:#1 (768 bit)
lifetime:86400 seconds, no volume limit
Note Although the output shows “no volume limit” for the lifetimes, you can configure only a time lifetime
(such as 86,400 seconds); volume-limit lifetimes are not configurable.
Configuring a service-ipsec Interface with a Dynamic Profile: Example
The following shows how to configure a service-ipsec interface with a dynamic profile:
ipv4 access-list acl1
10 permit ipv4 any any
!
interface service-ipsec1
ipv4 address 44.44.44.44 255.255.255.0
profile ipsec-profile1
tunnel source 100.0.0.1
service-location preferred-active 0/4/0
!
crypto isakmp
crypto isakmp policy 10
authentication pre-share
