Cisco IR1101 Manual

Technology SupportedDescriptionModem UsedSKU ID
Multimode LTE Advanced 3.0 for carriers that
operate FDD LTE 700-MHz (band 12),
700-MHz (band 29), 800-MHz (band 20),
850-MHz (band 5 CLR), 850-MHz (bands 26
Low), 900-MHz (band 8), 1800-MHz (band
3), 1900-MHz (band 2), 1900-MHz (PCS band
25), 1700-MHz and 2100-MHz (band 4 AWS),
2100-MHz (band 1), 2300-MHz (band 30), or
2600-MHz (band 7) networks. The multimode
Cisco LTE Advanced 3.0 NIMs are backward
compatible with Universal Mobile
Telecommunications Service (UMTS) and
Dual-Carrier High-Speed Packet Access Plus
(DC-HSPA+): 850-MHz (band 5), 900-MHz
(band 8), 1800-MHz (band 3), 1900-MHz
(band 2), 1700-MHz and 2100-MHz (band 4
AWS), and 2100-MHz (band 1).
Multimode LTE Advanced 3.0 for carriers that
operate TDD LTE 2500-MHz (band 41).
Multimode LTE Advanced 3.0 for carrier
aggregation band combinations: 1+8;
2+(2,5,12,13,29); 3+(7,20); 4+(4,5,12,13,29);
7+(7,20); 12+30, 5+30, and 41+41.
USA, Canada, Europe,
Latin America
EM7455P-LTEA-EA
LTE bands 1-5, 7, 8, 12-14, 17, 18-20, 25, 26,
28-30, 32, 38-43, 46, 48, 66, and 71.
FDD LTE 600 MHz (band 71), 700 MHz
(bands 12, 13, 14, 17, 28, and 29), 800 MHz
(band 20), 850 MHz (bands 5, 18, 19, and 26),
900 MHz (band 8), 1500 MHz (band 32), 1700
MHz (bands 4 and 66), 1800 MHz (band 3),
1900 MHz (bands 2 and 25), 2100 MHz (band
1), 2300 MHz (band 30), 2600 MHz (band 7).
TDD LTE 1900 MHz (band 39), 2300 MHz
(band 40), 2500 MHz (band 41), 2600 MHz
(band 38), 3500 MHz (bands 42 and 48), 3700
MHz (band 43), 5200 MHz (band 46).
United States, Europe,
Canada, Japan, Australia
and New Zealand.
LM960AP18P-LTEAP18-GL, Cisco
LTE Advanced Pro
Pluggable 3GPP Category
18
Supported only
in the IR1101
Base Unit. Not
supported in the
IRM-1100
Expansion
Module.
Note
GNSS is not
supported on the
CAT18 module.
Note
Product Overview
16
Product Overview
Modem Support

Cisco IR1101 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
SIM card slot	-
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.1D, IEEE 802.1Q
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
USB version	2.0
USB ports quantity	2
Combo SFP ports quantity	1
Ethernet LAN (RJ-45) ports	4
Output voltage	12 - 48 V
Power source type	DC
Power consumption (typical)	9.8 W
Operating altitude	-152.4 - 1524 m
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Safety	UL 60950-1, 2nd edition; CAN/CSA C22.2 No. 60950-1, 2nd edition, EN 60950-1, 2nd edition; CB to IEC 60950-1, 2nd edition
Flash memory	8000 MB
Storage media	Flash
Internal memory	4096 MB
Internal memory type	DRAM
Electromagnetic compatibility	47 CFR Part 15 B, EN 55032:2015, CISPR 32 Edition 2, CNS13438: 2006, EN 300 386 V1.6.1, ICES-003 Issue 6: 2016, KN 32: 2015, TCVN 7189: 2009, V-2/2015.04, V-3/2015.04, AS/NZ CISPR32, EN 61000-4-2, 3, 4, 5, 6, 8, 9, 16, 17, 18, and 29, CISPR24: 2010 + A1: 2015, EN 300 386 V1.6.1, EN 55024: 2010 + A1: 2015, EN 55035:2017, KN35: 2015, TCVN 7317:2003, QCVN 18:2014
Product color	Black
Routing protocols	BGP, EIGRP, HSRP, RIP-1, RIP-2
Data link protocols	IPv4, IPv6
Supported protocols	SCADA, DNP3, T101-104, Raw Socket TCP, UDP
Mobile network generation	Not supported
VPN support	Cisco Easy VPN Solution client and server NAT transparency Dynamic Multipoint VPN (DMVPN) Tunnel-less Group Encrypted Transport VPN Flex VPN
Firewall security	Cisco IOS
Security algorithms	256-bit AES, HTTPS, IPSec, SSL/TLS
Authentication method	Secure HTTP (HTTPS), FTP, Telnet Authentication Proxy
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	124.9 mm
Width	132.5 mm
Height	60 mm
Weight	1020 g
