Link time takes about 60 seconds. Fast flashing green LED 2 indicates DSL training. LED 2 on both VDSL2 SFP Modules
(CO & RT) turns solid green when the devices link up.
Removing the DSL SFP Module
Perform the following to remove the module:
Step 1 Remove the xDSL connection cable from the ports.
Step 2 Open the SFP-Pull with your finger and press it to the end.
Figure 20: SFP-Pull
Step 3 Grasp the SFP module between your thumb and index finger, and carefully remove it from the cage. Do NOT pull on
the SFP-Pull.
Figure 21: Grasp SFP Module
