Figure 16: LED 1
DescriptionStateIndicator LED
CPE Mode/RT Mode/Primary
Mode
OnLED 1 (Orange)
Customer Premises Equipment
(CPE) or Central Office (CO) LED
CPE Mode/RT Mode/Subordinate
Mode
OffLED 1 (Orange)
CO/CPE LED
Figure 17: LED 2
DescriptionStateIndicator LED
No DSL Connection
Possibly a bad cable, link, etc...
OffLED 2 (Green)
xDSL Status LED
IdleSlow FlashLED 2 (Green)
xDSL Status LED
TrainingFast FlashLED 2 (Green)
xDSL Status LED
ShowtimeSteadyLED 2 (Green)
xDSL Status LED
Product Overview
23
Product Overview
DSL SFP Overview
