Cisco IR809 Product Overview

There are two TNC connectors on the backside of the device. The TNC connectors are used to connect to the
4G modem. The SMA connector is for the GPS antenna.
Before choosing your antenna type and installation scenario, read through the following information.
Note
This section lists the supported Antennas and Cables for the Cisco IR809. For detailed information about
Cisco Antennas, please refer to the following guides:
• Connected Grid Antennas Installation Guide:
http://www.cisco.com/c/en/us/td/docs/routers/connectedgrid/antennas/installing/cg_antenna_install_guide.html
• Antennas for the Cisco 800 Series Routers:
http://www.cisco.com/c/en/us/support/routers/800-series-routers/products-installation-guides-list.html
An antenna lighting arrestor must be used when an antenna is installed outdoors. Install per the country’s
national electrical code requirements for lightning protection. The Lightning Arrestor for LTE antenna’s is
CGR-LA-NF-NF or CGR-LA-NM-NF.
Note
The following antennas and cables are available:
ANT-3-4G2G1-O
Description: Cisco Quinta 3 element 3-in-1 transportation antenna
• 2x 4G cellular, 1xGPS
• Color: Black radome
• RoHS compliant
• Environment: Outdoor
ANT-4G-OMNI-OUT-N
Description: Cisco outdoor omnidirectional antenna for 2G, 3G, and 4G LTE cellular
• UV-stable radome
• Mast-mounting bracket
• Applicable for both 2G and 3G solutions
• Domestic LTE 700 band and global LTE 2600 band
• Domestic cellular and global GSM
• WiMAX 2300 and 2500
Electrical Specifications:
